Exotronic 10A In-line Fuse Solar Connector


Notify me when available

You have already submited form for Default Title

Thanks for contacting us. We'll get back to you as soon as product / variant is back in stock.
863

DESCRIPTION

Enhance Your Solar System with the Exotronic 10A MC4 Compatible In-line Solar Fuse Connector

Upgrade your solar installations with our MC4 Compatible In-line Solar Fuse Connector, an essential component for any efficient and safe solar power system. Designed for simplicity and durability, this connector is an ideal choice for both professional and DIY solar setups.

Effortless Installation and Reliable Performance

Experience a hassle-free installation process with our user-friendly Plug & Play design. This connector is not only easy to integrate into your existing solar array but also ensures a secure and stable connection, vital for uninterrupted solar power generation.

Built for the Outdoors

Crafted to withstand the challenges of outdoor environments, our connector features a waterproof build, ensuring consistent operation even in adverse weather conditions. This durability makes it a trustworthy choice for all types of solar applications, from caravan rooftop arrays to larger industrial solar installations.

Safety and Quality Assured

With safety at the forefront, this connector is built using high-quality materials that ensure not only efficient energy transfer but also provide protection against environmental hazards. Its robust construction and safety features make it a reliable component in maintaining the integrity of your solar power system.


SKU: Exo-10A-MC4-Fuse

SPECIFICATIONS

Specifications

Specification Details
Waterproof and Dustproof (Mated) IP67
Waterproof and Dustproof (Unmated) IP2X
Rated Voltage 1000V DC (IEC)
Contact Material Tinned Copper
Insulation Material PC/PPO
Contact Material Copper Alloy, Tin Plated
Temperature Range –40°C to +90°C (IEC)
Upper Temperature Limit +105°C (IEC)
Degree of Protection (Mated) IP67
Degree of Protection (Unmated) IP2X
Flame Class UL94-V0
Locking System Snap-in
Contact Resistance of Plug Connectors 0.5mΩ
Safety Class II
Test Voltage 6kV (50Hz, 1min)
Salt Mist Spray Test, Severity Degree 5 (according to IEC 60068-2-52)
Rated Current 10A
Connector System Ø 4 mm

SKU: Exo-10A-MC4-Fuse
Barcode: 9361784001432
Model #: Exo-10A-MC4-Fuse
MPN: Exo-10A-MC4-Fuse
