Genasun 36V 8A GV-Boost Lead-Acid MPPT Solar Charge Controller

A compact voltage-boosting MPPT controller for charging 36V lead-acid battery banks from lower-voltage solar panels.


Get Notified When Stock Arrives

You’ve been added to the notification list. We’ll let you know when this product is available again.

Thanks for contacting us. We'll get back to you as soon as product is back in stock.
1

DESCRIPTION

Genasun 36V 8A GV-Boost Lead-Acid MPPT Solar Charge Controller

The Genasun GV-Boost GVB-8-Pb-36V is a specialist voltage-boosting MPPT solar charge controller designed for 36V lead-acid, AGM, gel, sealed and flooded battery systems. Unlike conventional solar controllers that step panel voltage down to charge a lower-voltage battery bank, the GVB-8 Boost is built to lift a lower-voltage solar panel output up to charge a higher-voltage battery bank.

This makes it a practical choice where a compact solar array needs to support a 36V battery system without relying on multiple small panels wired in series. It is well suited to properly designed RV, marine, portable, micro-mobility and off-grid applications where the solar panel remains within the controller’s input ratings and the installation environment is appropriate for an IP40 device.

Genasun’s high-speed MPPT technology continuously tracks the panel’s operating point, with the official datasheet listing 99 percent peak efficiency, 99+ percent typical tracking efficiency and 15 Hz MPPT tracking speed. In real-world conditions where panel voltage, heat and shade can change quickly, that fast tracking helps the controller stay aligned with available solar input rather than relying on slow sweep cycles.

  • Voltage-boosting MPPT design: Allows a lower-voltage solar panel to charge a 36V lead-acid battery bank when installed within the published input limits.
  • 36V lead-acid charge profile: Multi-stage charging with temperature compensation for lead-acid, AGM, gel, sealed and flooded battery types.
  • 325W recommended panel rating: Supports up to 325W maximum recommended panel power for the 36V lead-acid model.
  • Compact IP40 enclosure: Small 137 x 62 x 33 mm body with nickel-plated brass and stainless hardware.
  • Fast MPPT response: 15 Hz tracking speed and strong low-light performance for applications with changing solar conditions.

For the GVB-8-Pb-36V model, the datasheet lists a maximum recommended panel Vmp of 41V, maximum input panel voltage of 60V and recommended maximum panel Voc at STC of 50V. These figures are important when selecting a panel, particularly where cold weather can raise open-circuit voltage. The controller is rated for 8A panel input current, with Sunforge noting that panel ratings have increased since the GVB-8 was designed and that they are comfortable recommending panels with Imp up to 9A, provided maximum input power and voltage requirements are also respected.

The unit uses a 4-position terminal block for 10 to 30 AWG copper conductors and includes a built-in 10A fast-acting ATO fuse. It also provides LED status indication for standby, charging, current limit, charged battery and fault conditions, helping installation checks and troubleshooting after commissioning.

The GVB-8-Pb-36V is the standard IP40 model. It should not be exposed to water, and Genasun’s manual directs users to the GVB-8-WP model where waterproofing is required. For lead-acid versions, the manual also specifies use within 0.3 m of the batteries due to internal temperature compensation.

For systems needing a small, efficient and purpose-built way to charge a 36V lead-acid battery bank from a lower-voltage solar panel, the Genasun GVB-8-Pb-36V offers a clean, compact solution backed by detailed official specifications.

SPECIFICATIONS

Specifications

SpecificationValue
BrandGenasun by Sunforge
ModelGVB-8-Pb-36V
Product typeVoltage-boosting MPPT solar charge controller
Battery type36V Lead-Acid, AGM, Gel, Sealed, Flooded
Charge profileMulti-stage with temperature compensation
Nominal battery voltage36V
Rated panel input current8A
Maximum recommended panel power325W
Maximum recommended panel Vmp41V
Minimum panel voltage for charging5V
Minimum battery voltage for operation9.5V
Trickle charge to recover dead 0V batteryYes
Maximum input panel voltage60V
Recommended maximum panel Voc at STC50V
Input voltage range0 to 60V
Maximum input short circuit current8A
Maximum input current15A
Tracking efficiency99+% typical
MPPT tracking speed15Hz
Bulk voltage43.2V
Absorption voltage42.6V
Absorption time2 hours
Float voltage41.4V
Re-absorb, re-bulk voltage37.5V
Battery temperature compensation, referred to 25°C-84mV/°C
Electrical efficiency96% to 98% typical
Night consumption6mA
Operating temperature-40°C to 85°C
Maximum full power ambient70°C
Environmental protectionIP40, nickel-plated brass and stainless hardware
Connection4-position terminal block for 10 to 30 AWG wire
Fuse10A fast-acting ATO fuse rated for maximum battery voltage
Certifications listed by manufacturercETLus, CE, FCC, RoHS
Product weight185g
Product dimensions5.4 x 2.4 x 1.3 in, 13.7 x 6.2 x 3.3 cm
Warranty5 years

SKU: GVB-8-Pb-36V
HS code: 8504409580
Country of origin: US
Package length: 0.17 m
Package width: 0.08 m
Package height: 0.04 m

WARRANTY

Genasun Warranty Policy

This warranty policy applies to Genasun solar charge controllers supplied by us in Australia. As the Australian supplier or importer of these products, we support warranty claims for Genasun products supplied by us in accordance with the applicable manufacturer warranty and Australian Consumer Law.

Genasun solar charge controllers supplied by us are covered against defects in materials and workmanship for the warranty period applicable to the relevant product model range, subject to the product being selected, installed, operated, stored and maintained correctly and in accordance with the manufacturer's instructions.

This warranty applies to the original end-user purchaser of the product, as evidenced by a valid proof of purchase. The benefits given by this warranty are in addition to other rights and remedies available under law.

Warranty Coverage and Periods

This warranty covers Genasun solar charge controllers supplied by us. The warranty periods for each product model range are set out below.

Genasun Product Model Range Warranty Length Application / Notes
Genasun GV-5 Solar Charge Controllers 120 months Applies to all Genasun GV-5 charge controller models, including lead-acid and lithium variants, where installed and operated in accordance with the manufacturer's instructions.
Genasun GV-5-MOD Solar Charge Controller Modules 120 months Applies to all Genasun GV-5-MOD charge controller module models, including lead-acid and lithium variants, where installed and operated in accordance with the manufacturer's instructions.
Genasun GV-4 Solar Charge Controllers 60 months Applies to all Genasun GV-4 charge controller models, including lead-acid and lithium variants, where used within the product's rated specifications.
Genasun GV-10 Solar Charge Controllers 60 months Applies to all Genasun GV-10 charge controller models, including lead-acid and lithium variants, where used within the product's rated specifications.
Genasun GVB-8 Boost Solar Charge Controllers 60 months Applies to all Genasun GVB-8 boost charge controller models, including lead-acid and lithium variants, where correctly selected for the solar panel and battery voltage being used.
Genasun GVB-8-WP Waterproof Boost Solar Charge Controllers 60 months Applies to all Genasun GVB-8-WP waterproof boost charge controller models, including lead-acid and lithium variants, where installed and operated within the product's rated specifications.

The warranty period begins on the date the product is sold to the original consumer purchaser, as shown on the valid proof of purchase. A valid proof of purchase identifying the purchaser and date of purchase is required for all warranty claims.

Installer Responsibilities and System Design

Genasun solar charge controllers are installed into broader solar charging, battery charging, vehicle, marine, RV, off-grid or industrial electrical systems. Once installed, the product forms only one component of a larger system.

We do not provide installation services unless expressly stated in writing, and we do not supervise or control installation practices carried out by dealers, installers, contractors or end-users. The installer, system designer, integrator, dealer or end-user is responsible for ensuring that the product is suitable for the intended application and is installed correctly.

Issues or damage arising from incorrect installation, poor system design, incorrect configuration, incompatible equipment, inadequate protection, unsuitable mounting, unsuitable environmental conditions or failure to follow the manufacturer's instructions are not product defects and are not covered by this warranty.

Appropriate Installation

All Genasun solar charge controllers must be installed in accordance with the product manual, the manufacturer's installation instructions, applicable Australian Standards, relevant electrical, automotive, marine, solar or industry standards, and recognised industry best practice.

The installer must ensure that the product is used in an appropriate environment and within its specified ratings. Improper, unsafe, unlicensed, sub-standard or non-compliant installation may void or limit warranty coverage.

System Compatibility

The installer or integrator is responsible for selecting and using compatible components. This includes ensuring compatibility with solar panels, batteries, battery chemistry, battery voltage, charge profiles, loads, wiring, fuses, circuit breakers, connectors, mounting hardware and any other connected equipment.

Damage or underperformance caused by incompatible, incorrectly configured, undersized, oversized, unsuitable or improperly installed equipment is not covered by this warranty.

System-Wide Performance

Overall system performance depends on design, installation, configuration, solar panel selection, battery condition, usage, maintenance and environmental factors beyond the Genasun product itself. This warranty covers the quality of the individual Genasun solar charge controller supplied by us only. It does not guarantee the performance of the broader solar or electrical system into which the product is installed or integrated.

Issues such as insufficient charging, poor solar performance, incorrect battery charging, battery damage, voltage drop, nuisance faults, overheating, intermittent operation or operational shortfalls caused by system design, installation, configuration or connected equipment are outside the scope of this warranty.

Installation Location and Environmental Suitability

The installer must ensure that Genasun solar charge controllers are mounted, located, supported, ventilated and protected in a manner suitable for the installation environment.

Where relevant, the installer must allow for heat dissipation, ventilation, moisture exposure, dust, vibration, corrosion risk, electrical clearance, mechanical loading, access for inspection and service, and protection from unsuitable environmental conditions.

Damage caused by unsuitable mounting, inadequate ventilation, moisture, water ingress, dust, corrosion, excessive heat, vibration, insufficient clearance, unsuitable substrate selection or other installation environment issues is not a manufacturing defect and is not covered by this warranty.

System Protection and Fault Isolation

The installer must incorporate suitable protective devices and design measures appropriate to the product and installation type. This may include correctly rated fuses, circuit breakers, isolators, over-current protection, over-voltage protection, reverse-polarity protection, surge protection, correct cable sizing and other protective devices required by standards or best practice.

The installer is responsible for ensuring that a fault or failure in one component does not cause cascading damage to other components. Damage to Genasun products caused by inadequate system protection, poor fault isolation, incorrect protection settings or missing safety devices is not covered by this warranty.

Service Accessibility Requirement

Products must be installed in a manner that allows reasonable access for inspection, testing, servicing, removal and replacement. We are not responsible for additional labour, structural modification, access equipment, removal of fixtures, cabinetry, panels, flooring, trim, sealants, adhesives or other costs arising from installation methods that restrict reasonable access to the product.

Installation Documentation

We may require documentation of the installation when assessing a warranty claim. This may include photos of the product in its installed location, wiring diagrams, system layout, solar panel details, battery details, serial numbers, details of connected equipment, installer details, commissioning records, service history, fault logs, operating settings and maintenance records.

Failure to provide reasonable installation evidence may limit our ability to assess the claim.

Independence of Dealers and Installers

Dealers, resellers, installers and contractors act independently and are not agents, employees or representatives of Genasun, Sunforge or us unless expressly agreed in writing. We are not responsible for the acts, omissions, workmanship, advice, representations, installation practices or system design decisions of independent dealers, resellers, installers, contractors or third parties.

What This Warranty Does Not Cover

This warranty covers manufacturing defects or failures of the product arising from normal use in accordance with the manufacturer's instructions. It does not cover any failure, damage, performance issue, deterioration or loss caused wholly or partly by external factors, misuse, incorrect installation or circumstances outside the manufacturer's control.

  • Incorrect installation, wiring, connection or configuration
  • Incorrect product selection or application
  • Use outside the product's intended purpose
  • Operation outside the product's rated technical specifications
  • Incorrect solar panel voltage, battery voltage, battery chemistry or charge profile
  • Failure to follow the manufacturer's storage, usage, installation, operation or maintenance instructions
  • Alteration, modification, disassembly or tampering
  • Repair or service not carried out by a manufacturer-authorised repair facility
  • Application of foreign substances or contamination
  • Improper operation, misuse, abuse or neglect
  • Physical impact, accidental damage or mechanical damage
  • Corrosion or environmental damage outside the product's rated specifications
  • Lightning, surge damage or other acts of God
  • Use with incompatible, incorrectly rated or improperly configured third-party components
  • Damage caused by inadequate fusing, circuit protection, isolation or system protection
  • Damage caused by moisture, water ingress, dust, corrosion or unsuitable installation environments
  • Damage caused by excessive heat, inadequate ventilation or installation in an unsuitable location
  • Damage caused by vibration, movement, poor mounting or inadequate support
  • Normal wear and tear, cosmetic ageing, cosmetic deterioration or surface marks that do not affect product function
  • Failure to carry out reasonable inspection, cleaning, maintenance or servicing where required
  • Products with removed, altered, damaged or illegible serial numbers, rating labels or identification markings
  • Products purchased second-hand, from unauthorised channels, auction sites, liquidation sales or grey-market sources
  • Labour costs for removal, replacement, reinstallation or diagnosis
  • Freight, travel, call-out costs or access costs unless otherwise required by law
  • Products not returned for assessment when reasonably required
  • Consequential or incidental loss, including damage to other equipment, downtime, loss of use, loss of revenue or economic loss, to the extent permitted by law

Warranty Assessment and Remedy

If a Genasun solar charge controller supplied by us is found to be defective within the applicable warranty period, we will, at our discretion and subject to the requirements of Australian Consumer Law, arrange a repair, replacement, store credit, refund or another appropriate remedy.

Products may need to be returned for assessment before a warranty claim can be approved. Where required, the product must be returned with dated proof of purchase, product details, serial number if available, installation information and a clear description of the fault.

If the product is required to be returned to Genasun, Sunforge or another nominated assessment location for inspection or repair, a return authorisation process may be required before the product is sent. Products sent without the required return authorisation or documentation may not be processed.

If a product is assessed and found not to be defective, or the issue is found to be caused by an excluded factor, the claim may be rejected. In that case, assessment fees, freight, insurance and return costs may be payable by the customer to the extent permitted by law.

Labour costs for removing, replacing, reinstalling or diagnosing a product are not covered by this express warranty unless otherwise required under Australian Consumer Law.

Making a Warranty Claim

If you suspect a fault with a Genasun product supplied by us, do not immediately remove or uninstall the product unless it is unsafe to leave it in place or unless authorised as part of the warranty process. Premature removal may cause further damage or make it difficult to determine the original cause of the issue.

  1. Contact us: Contact us with your dated proof of purchase, product model, serial number if available, and a description of the fault.
  2. Provide product and installation information: We may request installation photos, wiring details, solar panel details, battery details, connected equipment details, operating settings, measurements or service history to assist with assessment.
  3. Assessment and troubleshooting: We may ask for safe checks, photos, voltage readings, current readings, testing information or other details to determine whether the issue appears to be a product fault or is caused by installation, configuration, connected equipment, environment or misuse.
  4. Return for inspection if required: If the fault cannot be confirmed remotely, the product may need to be returned for inspection, testing, repair or replacement assessment. Return instructions will be provided where required.
  5. Outcome: If the product is confirmed to be faulty and covered by this warranty, we will advise the available remedy. If the product is found not to be faulty, or the issue is caused by an excluded factor, the claim may be rejected.

Remedies Under Warranty

If a defect covered by this warranty is confirmed, we may provide one or more of the following remedies, subject to the circumstances of the claim and the requirements of Australian Consumer Law:

  • repair of the product;
  • replacement of the product;
  • store credit;
  • refund;
  • supply of replacement parts; or
  • another appropriate remedy required by law.

Repair or replacement under this warranty does not restart or extend the original warranty period. The warranty continues from the original purchase date.

Manufacturer Support

Genasun products may be assessed, repaired or replaced through Sunforge, Genasun or another nominated service process. Where available, we may assist customers in arranging assessment, but any manufacturer service is subject to the manufacturer's own process, requirements and continued availability.

Where a manufacturer return authorisation is required, the product must not be sent until the required authorisation has been issued and the return instructions have been provided.

Australian Consumer Law

This warranty is in addition to other rights and remedies available at law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
