Votronic Tank Level Sensor FL 5530

Precise Capacitive Tank Level Monitoring for Mobile and Off-Grid Water Systems

Reliable Measurement Without Pressure-Related Errors

The Votronic Tank Level Sensor FL 5530 uses advanced capacitive measuring technology to deliver accurate, real-time fluid level data for fresh water, waste water, and grey water tanks. Unlike traditional float or pressure-based sensors, this system operates independently of tank pressure, eliminating false readings caused by overpressure, pressure filling, or sloshing during transit. This makes it an ideal choice for caravan water tanks, motorhome grey water systems, marine fresh water monitoring, and other mobile applications where consistent accuracy is critical.

Designed for both short-term and continuous operation, the sensor provides a linear 0–2.2 V signal output proportional to the tank level (0–100%), ensuring seamless integration with compatible Votronic display units and control panels.

Flexible Installation for Metal and Plastic Tanks

The FL 5530 supports top-mount or side-wall installation, with an adjustable probe length that can be cut to fit tank heights from 30 cm to 100 cm. The included stainless steel conductor and flexible cord probe allow precise positioning, while the watertight screwed cable gland ensures a secure, moisture-resistant seal. Suitable for aluminium, steel, stainless steel, and plastic tanks (up to 8 mm wall thickness for plastic), this sensor adapts to a wide range of tank materials and configurations.

A cleaning opening is required for installation, and the sensor module’s compact, sealed design (IP 67) withstands frost, moisture, and underfloor mounting conditions—making it suitable for problematic locations such as exposed chassis-mounted tanks.

Key Features at a Glance

• Capacitive sensing eliminates pressure-induced measurement errors
• Adjustable probe length suits tank heights from 30 cm to 100 cm
• IP 67 sealed electronics resist frost, moisture, and underfloor conditions
• Wide 8–32 V operating range compatible with 12 V and 24 V systems
• Reverse polarity, overvoltage, and short-circuit protection for robust operation
• Compatible with Votronic S-series displays, Info Panel Pro, VPC Jupiter, and VPC Terra

Built for Demanding Environments

The sensor’s fully potted electronics and corrosion-resistant materials ensure long-term reliability in coastal, humid, or high-vibration settings. Compliance with EN55014-1, EN61000-6-1, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN62368-1, and EN50498 standards confirms its electromagnetic compatibility and safety, while RoHS compliance supports environmentally responsible manufacturing.

With a low current draw of just 4–7 mA, the FL 5530 minimises battery drain in off-grid setups, preserving power for essential systems. Its 3-core screw terminal connection simplifies wiring to compatible displays, and the included fastening screws and tank wall bushing streamline installation.

Applications

• Fresh water level monitoring in caravans, RVs, and camper trailers
• Grey water and waste water tank measurement in marine vessels
• Underfloor tank installations where frost and moisture resistance are essential
• Retrofit upgrades for older Votronic tank display systems (compatible since 1987)

Upgrade Your Tank Monitoring Today

Equip your mobile water system with the Votronic FL 5530 capacitive tank sensor for precise, maintenance-free level measurement. Whether you're refitting a caravan or building a custom off-grid setup, this sensor delivers the accuracy and durability needed for worry-free travel. Add to your system now and monitor with confidence.
